PowerPlex® CS7 System

DC6613_PowerPlex--CS7-System--100rxn_3
View information on global supply logistics
customize-this-small

Multiplex STR Assay for Relationship Testing and Human Identification

  • Co-amplification and 3-color detection of 7 STR loci: LPL, F13B, FESFPS, F13A01, Penta D, Penta C and Penta E
  • Size standard is included and hot-start Taq DNA polymerase is provided in the master mix

Size

Catalog number selected: DC6613

$ 1,760.00
Your price:
Add to Cart
This product is discontinued
Add to Helix
This product is available under our Early Access program - Learn More
This product is available under our Catalog (FT) program - Learn More
PowerPlex® CS7 System
100 reactions
$ 1,760.00
Your price: Log in

Multiplex STR Assay for Relationship Testing and Human Identification

The PowerPlex® CS7 System allows co-amplification and three-color detection of seven STR loci, including LPL, F13B, FESFPS, F13A01, Penta D, Penta C and Penta E. All seven loci are amplified simultaneously in a single tube and analyzed in a single injection. The PowerPlex® CS7 System provides all materials necessary to amplify STR regions of purified genomic DNA.

This system contains two loci, Penta D and Penta E, that overlap with the loci included in the PowerPlex® 16, 16 HS, 18D, 21 and Fusion Systems, allowing detection of sample mixup when used together. This feature allows the PowerPlex® CS7 System to be used as a confirmatory kit in paternity applications using the five unshared STR loci to supplement the genotype and increase the available information for greater discrimination.

The PowerPlex® CS7 System is compatible with the Applied Biosystems® 3130,  3130xl and 3500 Genetic Analyzers.

The PowerPlex® CS7 System
8832TA-W
A single-source template DNA (0.5ng) was amplified using the PowerPlex® CS7 10X Primer Pair Mix. Amplification products were mixed with Internal Lane Standard 600 and analyzed with an Applied Biosystems 3130 Genetic Analyzer using a 3kV, 5-second injection. Results were analyzed using GeneMapper® ID software, version 3.2, and PowerPlex® CS7 panel and bin files.

The PowerPlex® CS7 Allelic Ladder Mix

8831TA-W
The PowerPlex® CS7 Allelic Ladder Mix was analyzed with an Applied Biosystems 3130 Genetic Analyzer using a 3kV, 5-second injection. The sample file was analyzed with the GeneMapper® ID software, version 3.2, and PowerPlex® CS7 panel and bin files. Please see the protocol for more details.

Rapid Processing Solutions for PowerPlex® Systems

The 5X AmpSolution™ Reagent, SwabSolution™ Kit and PunchSolution™ Kit allow fast and simple processing of swabs and punches for analysis with various PowerPlex® Systems, including the PowerPlex® Fusion, 21, 18D, 16 HS, ESX, ESI, CS7 and Y23 Systems. These products are intended for preparation of single-source reference, database and paternity samples where sample purification is unnecessary.

Which Product is Right for Me?

Take me to the Product Selector

Specifications

What's in the box?

Item Part # Size Concentration Available Separately

2800M Control DNA

DD710A 1 × 25μl 10ng/μl View Product

Internal Lane Standard 600

DG107A 1 × 150μl View Product

PowerPlex® CS7 Allelic Ladder Mix

DG147B 1 × 50μl

PowerPlex® CS7 10X Primer Pair Mix

DK157B 1 × 250μl

PowerPlex® HS 5X Master Mix

DP101A 1 × 500μl

Water, Amplification Grade

DW099A 2 × 1,250μl View Product

Certificate of Analysis

Search by lot number

Use Restrictions

Not For Medical Diagnostic Use.

Storage Conditions
